Case Study on Model Making of Construction Crane

1、 Project Overview

This project aims to create a 1:50 scale tower crane model, with a focus on reproducing the main structure, lifting mechanism, and support system of a real crane. The height of the model is about 80 centimeters, and it adopts a production scheme of metal main structure combined with plastic details, pursuing a 90% restoration degree, highlighting the power and industrial beauty of construction machinery.

2、 Material selection and main structure

The main tower is made of precision galvanized steel pipes to ensure verticality and structural strength. The balance arm and crane arm are constructed with aluminum alloy profiles and reinforced with internal ribs. The counterweight block is made of solid cast iron to ensure the stability of the model. The cab is injection molded with ABS plastic and the windows are made of transparent acrylic.

3、 Main component production

Tower structure: segmented design, with each tower section connected by threads to ensure installation accuracy

Rotary mechanism: using micro bearings to achieve smooth 360 degree rotation

Lifting system: Galvanized steel cables are used for the steel wire rope, and the hook assembly is precision cast brass

Supporting frame: I-beams are made of steel plates laser cut and welded into shape

4、 Detail processing technology

Safety barrier: made of welded stainless steel wire, with uniform and consistent spacing

Operation platform: Anti slip steel plate adopts etching process to express texture

Hydraulic system: Copper pipes are bent and formed, and micro metal parts are used for joints

Electrical system: colored insulated wires are used for electrical wiring, and the details of the distribution box are complete

5、 Painting process flow

Adopting a specialized coating scheme for construction machinery:

Surface treatment: All metal parts undergo phosphating treatment to enhance paint adhesion

Primer spraying: Epoxy primer is sprayed as a whole to fill subtle defects

Main color coating:

Main structure spraying engineering machinery yellow

The counterweight block maintains the original color of cast iron and is sprayed with transparent protective paint

Spray warning stripes on the end of the crane arm

Identification restoration: The safety warning label adopts water transfer printing technology, and the text is clear and recognizable

6、 Aging and texture expression

Emphasize structural gaps and bolt details using stain solution

Dry sweeping metal color shows wear on frequently rubbed areas

The counterweight is sprayed with slight rust to enhance its realism

Oil stain effect on the hydraulic rod area

7、 Implementation of movable functions

The lifting hook can move up and down

Adjustable boom angle

The rotating platform can rotate 360 degrees

Leg height adjustable

8、 Quality requirements

All structural components are securely installed without any looseness

The moving parts run smoothly without any jamming

Uniform coating, no color difference or missed spraying

The details are complete and intact, and the installation position is accurate
